The Product

Noiseless Steel is an acoustically constructed product specifically designed to reduce noise and vibrations. Paragon Manufacturing, Inc. (PMI) has designed and constructed sandwiched steel panels consisting of two sheets of metal with a visco-elastic inner layer that results in a metal/plastic/metal (MPM) panel. Quiet equates to quality in any application and PMI's acoustically designed panels help reduce noise and vibration by damping structure-borne noise, insulating against air borne sounds, and damping inherent vibrations. Typical industrial applications include uses on chutes, machinery covers, and compressors with expected noise level reductions of 10-20DBa.
The Benefits
Quiet equates to quality. Reduced noise level of 10-20DBa. A variety of materials can be used for the sandwiched steel panels (e.g. Deep-drawn steel, Stainless Steel, Aluminum, Plastic-laminated or enameled sheet metals, etc). Asymmetrical size and material types available. Noiseless Steel panels can be selected to complement the strength of the structure. Overall size/thickness will remain the same or be less than current damping application. Machine tool panels can be directly mounted on the machine without insulating spacers. Competitively priced with other damping materials. Panels, chutes, cabinets, and hood can be customized to meet your specifications.
The Features
The standard Noiseless Steel panel is a sandwich of sheet steel enclosing a visco-elastic inner layer with a high damping ability. Noiseless Steel panels can also be supplied in special materials, such as deep drawing steel, vehicle body grade or stainless steel, aluminum, and plastic-laminated or enameled sheet metal facings. Different materials can be combined - for example stainless steel on one side and aluminum on the other. Contact corrosion is effectively prevented, since the plastic inner layer isolates the plates from each other. Most industrial painting methods can be used and this provides further protection against corrosion. Some applications may benefit from the use of double-walled construction using two Noiseless Steel panels connected by strips or bolts. To enhance noise absorption, the gap between the panels may be filled with mineral wool or some other form of sound-absorbent material.
